Description

Upgrade your 2005-2008 Ford F-250/350 (Built Before 7/30/07) by replacing the damaged or worn steering gear with the RedHead Steering Gears 2768 Steering Box (4-Bolt Cover). With over 40 years of expertise in steering boxes, RedHead, a family-owned and operated business, ensures quality and durability. Crafted from top-notch materials, each RedHead Steering Box surpasses the strength of the original equipment unit. Designed for a seamless, direct-fit installation, the Steering Box fits effortlessly into the factory location.

Features:

• Remanufactured
• Direct-Fit Replacement
• Meets & Exceeds Factory Specs
• Shafts Are Flame Sprayed Or Replaced As Needed
• New Control Valves Installed On Some Applications
• Housing Are Machined And Needle Bearings Installed
• Sealing Surface Polished To A Higher Polish Than New
• Sector Shaft Checked On A Lathe For Straight And True
• Worm And Piston Assembled With New Precision Fit Steel Ball Bearings

Specs:

• Ratio: 18:1 (4 Turns)
• Input: 27 Splined with Single Flat
• Output: 33 Spline Sector w/ 3 Master Splines, Large Shaft (No Lock Washer on Sector Shaft)
• Fittings: O-Ring
• Weight: 33.00 lbs

Notes:

For 2008 models, please check production date. This unit is for models produced until 07/2007.
